5 HP Two-Stage Industrial Air Compressors

Splash-lubricated (R-Series) models use a simpler lubrication method suited for standard-duty applications up to 175 PSIG. Pressure-lubricated (PL-Series) models actively circulate oil under pressure to critical components, enabling higher pressure ratings up to 250 PSIG and improved durability for continuous, heavy-duty industrial operation.

At 100 PSIG, displacement is approximately 19.5 CFM. At 125 PSIG, delivery ranges from 17.3 to 19.1 CFM depending on the model. Output decreases progressively at higher pressures, with PL-Series models delivering 13.6 CFM at 250 PSIG, balancing pressure and flow for specific application needs.

These 5 HP two-stage compressors are available in tripod-mounted, vertical tank-mounted, and horizontal tank-mounted configurations. Tank-mounted versions typically include an 80-gallon receiver in either orientation, giving facilities flexibility to choose the footprint and installation style that best fits their available space.

These compressors support 208-230V single-phase and 208-230/460/575V three-phase configurations at 60 Hz. This range of electrical options allows the units to be installed across a wide variety of industrial facilities without requiring specialized electrical infrastructure upgrades in most cases.

These units operate at a relatively quiet 65-72 dBA, which is comparable to normal conversation or light traffic noise. This low noise output, combined with the direct drive design, makes them suitable for use in shared workspaces without requiring extensive additional soundproofing.

Every package includes a standard 2-year warranty covering the compressor package. Buyers can also opt into the Platinum 10-Year Extended Warranty program specifically covering the airend, providing significant long-term protection and reducing total cost of ownership over the life of the equipment.
